Dual Power Automatic Transfer Switch JGQ3-100
The JGQ3 Series ATSE is an intelligent device integrating switch and control, no external controller needed. It suits 440V/100A industrial power systems. With voltage/frequency monitoring, it offers millisecond - level switching, ensuring uninterrupted power transfer. It has a visible breakpoint for safety, multiple operation modes for emergencies, and meets IEC 60947-6-1, providing reliable power security.
Rated Voltage 440V AC
Rated Current 100A
Frequency 50Hz
Switching Time≤20ms (Motor-driven mechanism)
Safety FeaturesElectrical & Mechanical Interlocks
Application ScenariosMain-Standby Power & Dual-Load Systems
Compliance StandardsIEC 60947-6-1
Why Choose Us
19 R&D Experts, 400+ Patents
A dedicated team driving innovation and securing over 400 patents.
12M Units/Year
12 million pepper grinders produced annually with 36 molding machines and 12 assembly lines.
100% Quality Inspection
Ensuring food-grade safety with rigorous material checks.
Trusted by Top Brands
Long-term partner of OXO, Salter, GEFU, and more.
Product Feature Description

1. Overview

JGQ3 series dual-power automatic transfer switch (ATSE) is an integrated unit combining switching and logic control, without the need for an external controller. It truly realizes the mechanical and electrical integration of an automatic transfer switch. Suitable for AC 50Hz, rated voltage up to 440V, and a rated heating current of 100A, it is ideal for industrial and enterprise power distribution systems.

The switch features voltage detection, frequency detection, communication interface, electrical and mechanical interlock, and can perform fully automatic operation, remote control, forced “0”, and emergency manual operation. It is widely used for automatic switching between main and backup power sources or for the safe isolation and conversion of dual-load systems.

The control circuit board issues logic commands to drive a motor that activates the main switch mechanism, quickly breaking or connecting circuits and ensuring safe isolation with visible status indication.

2. Structural Description

  1. Electrical Button: Controls internal power supply for the control circuit. When set to “Auto”, the switch operates fully automatically. When set to “Manual”, the switch can only be manually operated.
  2. Operate Handle: Used for manual operation. Must be used when the electrical button is in the “Manual” position.
  3. Mechanism Padlock: Used for maintenance. First set the switch to “0” with the handle, then apply the padlock. This cuts off internal control power, disabling both automatic and manual switching.
  4. Indicator: Shows the working state of the switch (I, O, II).

3. Main Technical Parameters

  1. Compliance Standards: IEC947-6-1, GB14048.11
  2. Rated Working Voltage (Ue): AC415V
  3. Rated Turn-On Capacity (A Rms): 10Ie
  4. Rated Breaking Capacity (A Rms): 8Ie
  5. Rated Heating Current: 100A
  6. Rated Insulation Voltage: 750V
  7. Rated Impulse Withstand Voltage: 8kV
  8. Rated Working Current: 100A
  9. Rated Short-Circuit Current: 7kA
  10. Rated Limiting Current: 100kA
  11. Conversion Time: 10s

4. How to Use

  1. Fully Automatic Function: When the main power supply fails, the switch automatically transfers to the standby power supply. When the main power is restored, it automatically switches back.
  2. Forced “0” Function: Press the forced “0” button to cut off both power sources.
  3. Remote Control Function: Press “I” for the main power, “II” for the standby power, or “0” to cut off both power sources remotely.
  4. Function Selection: Select the required function and perform wiring according to the selected feature.
  5. Ordering: Specify the switch model, current rating, and required functions when placing an order.
Dual Power Automatic Transfer Switch JGQ3-100
Other Parameters
  • Product information
    • Brand Name EJEJG
    • Pole Configuration 3P/4P
    • Enclosure Protection IP65
    • Auxiliary Contacts 2NO + 2NC (Standard)
    • Control Voltage Ezcad
    • Cooling Method Air Cooling
    • Configuration Bench top
    • Feature ≤2000m
    • Standards Compliance IEC 60947-6-1, GB/T 14048.11
    • International Approvals CE, RoHS
    • Weight 3.5kg (3P), 4.2kg (4P)
    • Dimensions 220×150×85mm (3P), 260×150×85mm (4P)
